Yamaha Reface Tonewheel Drawbar Organ

Amplifiers and Speakers

• Amplifiers 2 W x 2
• Speakers 3 cm x 2

Power Supply

• Power Consumption 6 W (When using PA-130 power adaptor)
• Battery Life Approximately 5 hours
• Auto Power Off Yes
• Power Supply Adaptors PA-130 or an equivalent recommended by Yamaha
• Batteries Six “AA” size batteries or Ni-MH rechargeable batteries

Accessories

• Included AC adaptor*, MIDI breakout cable, Owner’s Manual, Warranty* *May be included depending on your locale

Voices

• Number of types 5 Organ types
• Effects Rotary Speaker, Distortion, Reverb

Size/Weight

• Dimensions Width 530 mm (20 7/8")
• Height 60 mm (2 3/8")
• Depth 175 mm (6 7/8")
• Weight 1.9 kg (4 lbs, 3 oz) (not including batteries)

Keyboard

• Number of Keys 37 keys
• Type HQ mini (High-Quality mini)
• Initial Touch Yes

Tone generation

• Maximum Polyphony 128
• Engine AWM (Organ Flutes)

Connectivity

• DC IN DC IN (12 V) jack
• Headphones PHONES (6.3 mm, stereo phone jack)
• MIDI MIDI (mini-DIN IN/OUT)
• AUX IN AUX IN (3.5 mm, mini stereo phone jack)
• OUT PUT L/MONO, R (6.3 mm, TS phone jack, unbalanced)
• USB TO HOST USB (TO HOST)
• Pedal Type FOOT CONTROLLER: FC7 (optional) (to adjust the volume)
